Features :
• 140 hours of operation in Angle Measurement Mode on 4AA batteries - better than any other model
• Unmatched speed and accuracy
• Vertical angle correction provides ±5" accuracy
• Large, high-contrast, back lit LCD display
• Compact, lightweight, sets up in seconds
• Simple operation - single side display
• Removable handle
• 360° rotating telescope
• Dual quick-sights: top and bottom of telescope
• Water and dust proof
• Built-in tribrach with bubble vial
TECHNICAL SPECIFICATIONS
TELESCOPE
Length : 152 mm
Objective lens : 45 mm
Magnification : 30x power
Field of view : 1°30’
Resolving power : 2.5" power
Minimum focus : 1m
Stadia ratio : 100
Stadia constant : 0
Sighting collimator : Double
ELECTRONIC ANGLE MEASUREMENT
Method : Absolute Reading
Detecting : 2 horizontal sides, 1 vertical sides
Minimum reading : 1"/5" arc seconds, 1mgon/2mgon
Accuracy : 5 arc seconds
Diameter Circle : 71mm
DISPLAY
Unit : 2 sides
OPTICAL PLUMMET TELESCOPE
Magnification : 3x power
Field of view : 3°
Focusing : 0.5m~∞
LEVEL SENSITIVITY
Plate level : 40"/2mm
Circular level : 10"/2mm
WATER PROTECTION : IP66 rating
POWER SUPPLY : 4AA batteries
OPERATING TIME
Theodolite only : 140 Hours
Laser only : 80 Hours
Theodolite and Laser : 45 Hours
OPERATING TEMPERATURE : -20 to +50 degrees C
WEIGHT : 9.26 pounds (4.2kg)
LASER POINTER
Method : Focusing
Wave Length / Power : 633nm / 0.6mW
Laser Class : Class II
COMPENSATOR
Tilt Sensor : Vertical
Compensator Range : ±3
UNTUK HARGA KAMI AKAN BERIKAN MELALUI PENAWARAN DENGAN HARGA TERBARU DAN HARGA TERBAIK.
Silahkan Hubungi Kami Via Email / Telp Kami Siap Membantu Keperluan Anda :
Telp : (021) 5694 2888, 5696 8845
Telp : (021) 5696 8763 HP : 081586838888
